Model

  UL-15RBEAM

Electrical

Voltage

AC 100-240v, 50/60Hz

Power consumption

450w

Ballast

Electrical ballast

Source

Lamp

Osram Sirius 15R 330w

Output Lumin

70000 lm at distance of 20 meter

Color temperature

7500K

Average lifespan

2000h

Mechanical

Gobo

8 Rotating gobo + 4 iris

Color

14 colors+open

Prism

8 facet rotating prism

Dimmer

0-100% linear dimmer

Frost lens

0-100% wash effect

Strobe rate

1-13Hz

Focus

linear adjustment

Motor

14

Fans

ADDA

Optical

Lens

High precision optical lens

Movement range

Pan

540° (16 bit) electric correction

Tilt

270° (16 bit) electric correction

Control & program

Control mode

DMX 512, master slave, sound active, auto mode

Channel

16 CH

Data in/out

3-pin/5-pin XLR

Other functions

Lamp ON / OFF can be controlled by controller

Display

LCD screen

Packing details

Dimension

420 x 370 x 550mm

N.W.

23kg
